MirAqua Ultrasonic Water Level Sensor
Sensor Ultrasónico de Nivel de Agua MirAqua
Know your water level in real time — from anywhere
Non-contact ultrasonic level sensor for cisterns and selected tinaco installations. Measures distance to the water surface, converts that to level/volume, and can support low-level alerts and consumption history. Final installation depends on tank geometry, access, humidity, mounting position and connectivity.
Specifications
- Sensor Type
- Ultrasonic time-of-flight (non-contact)
- Controller
- ESP32-class connected controller
- Data
- Level/volume history and configurable alerts
- Installation
- Mounted above waterline with clear measurement path
- Connectivity
- Wi-Fi or project-specific gateway depending on site
What's Included
- Ultrasonic sensor unit
- Weather-resistant controller enclosure
- Mounting hardware
- Dashboard access
- Alert configuration
- Professional installation in the Los Cabos service area
How It Works
The sensor emits an ultrasonic pulse toward the water surface and measures the return time. With the tank depth and usable geometry configured, MirAqua converts that distance into a level estimate and, where geometry is known, an estimated volume.
What You’ll See
The monitoring experience can include current level, history, low-level alerts, fill-event visibility and consumption trends. Exact features depend on the installed controller and connectivity configuration.
Why Non-Contact Measurement
The sensing face remains above the water instead of being submerged, which can reduce exposure to mineral scale and fouling. Ultrasonic sensing still requires a clear measurement path and appropriate mounting; tanks with difficult geometry may be better suited to pressure or other sensing methods.
